Fireproof mine conveyor belt 1000 mm wide. PVG SW/1 EN 14973, class C1, Lviv region.

Fireproof tapes with tensile strength of 800 N/mm, 1000 N/mm, 1250 N/mm, 1400 N/mm, 1600 N/mm, 1800 N/mm, 2000 N/mm, 2500 N/mm with the number of spacers from 3 to 5, width from 800 mm. up to 2000 mm. DSTU 7306:2013 are intended for use in underground mines for the extraction of combustible and non-combustible minerals, in methane and non-methane zones classified as "A", "B" and "C" of the methane explosion category and in workings classified as "A" and "B" according to the danger of coal dust explosion. Conveyor belts consist of layer-by-layer traction frames with a textile core: the main material is fabric EP
These tapes are made in accordance with very strict standards in terms of resistance to fire and static electricity. They comply with international standards, such as: EN14973 in Europe, MSHA in the USA, VVUU in the Czech Republic and Ukraine, etc. Tape type: PVG SW/1 fire resistant Tape strength, N/mm: 136
800, 1000, 1200, 1400, 1600, 1800, 2000, 2500, 3150Материал каркаса ленты:EBEB, EBPBТолщина резиновой футеровки, мм:
не меньше 2+2LКоличество прокладок:1Ширина ленты от 800 до 2000 мм.Огнестойкая шахтная конвейерная лента PVG SW/1 1600/1-1000 4+2L  шириной 1000 мм.соответствует стандарту EN 14973, класс C1 для подземных работ
- type of tape - mine flame-resistant rubber fabric;
- tape width, mm - ISO 22721 - 1000+/-1.5%; 140
-прочность ремня в продольном направлении, ISO 283 Н/м - 1600 не менее;
- the number of spacers, pcs. - 1;
- type of lining fabric - Solid-Woven Polyester (SW); - working temperature -5+50 degrees - tape strength, ISO 283, N/m - 1600 not less;
-thickness of the working gasket, ISO 583, mm - 4+1.0/-0.2;(//tractor-service.com)
-thickness of non-working gasket, ISO 583, mm - 2+1,0/-0,2;
- maximum burning time of one sample out of six after extinguishing the ISO 340 flame, sec. no more :
with covers - 15
without fenced - 15
-surface electrical resistance, ISO 384, Ohm no more - 3*8*;
Physico-mechanical rubber gauges for tape covers:
1) conditional tensile strength, ISO 37, MPa, not less than -15.0;
2) relative elongation at break, ISO 37.% not less than -350.0;
3) volume loss, ISO 4649, no more than 200.0; 154
4) твердость по Шору А, ISO 868, единиц не менее - 75
