Conveyor tape, Dnipropetrovsk region.

BKNL-65 100-1400*3 0/0 (3.6 mm) (3 fabric layers, 3.6 mm thick)
Rubber fabric conveyor conveyor belt from leading domestic and foreign manufacturers for various sectors of industry (mining, metallurgical, mineral, cement, construction, food, paper, agricultural, sugar, sea and river ports, grain terminals,,Elevators, quarries and sand quarries,power plants).
The company's priority is prompt delivery to any region, each request is treated individually, a high level of service and qualified staff, we perform repair work, tape splicing and cutting to size. Services for applying chevrons to the surface of a conveyor belt.
Rubber fabric conveyor belt single-layer and multi-layer.
Parameters of multi-layer rubber fabric tapes: — tensile strength in the longitudinal direction from 250-3500kN/m, number of pads from 2-6, width from 400-2200mm, full thickness of the tape from 8-40mm, core thickness from 2.8-15.5mm, cover thickness from 2-12mm, length of one a segment of 100-300m.(//tractor-service.com)
Depending on the purpose, conveyor belts differ in the following varieties:
1. General purpose: wear-resistant, wear-resistant — for the transportation of all materials, including sharp and highly abrasive ones (crushed stone, ores, sand, clay, fossils, etc.), number of pads от 3-6, strength от 315-3150kN/m, standard width от 500-1800 mm., lining thickness: working от 4-12 mm; not working from 2-8 mm., class of lining rubber: ordinary, increased wear resistance, high wear resistance, puncture resistance.
2. Rubber rope conveyor belts — for transporting bulk materials of any granulometric composition in trunk, long inclined conveyors (coal, ore, coke, metal., ceramic and chemical raw materials, chemicals, in ports, etc.) in the range of rab. t up to -30⁰С (for frost-resistant up to -60⁰С) up to +60⁰С, durable. from 1000-5400kN/m, width from 800-2600 mm., thickness. cover art ot6-14mm, not slave. from 5-10 mm, thickness. cable ot4-10mm, variety (general purpose, flame retardant, flame retardant).
3. Tubular conveyor conveyor belt — for transporting loose materials with conveyor rotation (sand, chemical raw materials, talc, in ports, cement, fertilizers, slag, grains), the belt is rolled into a tube in the main section of transportation, and remains in a horizontal position in the transition section (loading and unloading), compact in operation, min. loss and contamination during transportation of dusty material, pipe diameter от 100-500 mm., width tapes from 450-1900 mm., min. the turning radius is 30-150 m., the length of the transition section is 2.5-12.5 m.

"
