Band welding machine, Kharkiv region.

Description
Tape-welded apparatus

Band saw welding system:

Just follow the instructions for the parameters we give for the width and thickness of the band saw.

The ends of the welding band saw are placed on the clamping jaws, close the clamping jaws and press the start button. The ends of the band saw are clamped with special high-speed saw clamps. After pressing the welding lever, the automatic welding cycle begins (a pulse of welding current passes from the welding transformer). The block with two ends reaches the temperature of formation within the shortest time in seconds to restore the plasticity of the metal in the zone of the welding seam, and in the adjacent areas of the bandsaw, heat treatment (annealing) of the welding joint is performed. The device allows welding and annealing in one installation without adding any material. Thus, the plasticity of the band saw is restored. The welding current is turned off automatically upon completion. The quarrel is over.

Technical characteristics:

Parameter name Значение
Width of welding saws, mm 10-42
Thickness of welding saws, mm 0.4-1.5
Power consumption, kW 4.5
Voltage of the supply network, V 380
Productivity of quarrels in time 15
Dimensions, mm 400x400x300(//tractor-service.com)
Mass, kg 39

Ability to work with a wide range of wood band saws, bimetallic band saws, metal band saws and band knives.

Fast welding, economical and long-lasting welding of a band saw.

We manufacture the best high quality band saw butt welding machines with after sales support. Contact us to order a band saw butt welding machine right now.

We produce RYTM sawmills, spare and consumable parts, as well as:

Grinding machine with an abrasive or furrow wheel
Splitting machine for a band saw
Welding machine for band saws
Electronic ruler for a sawmill
Monoblock for switching from manual carriage lifting to electric.
