1-row precision seed drill, economy, СИ10, Kyiv

The drill is designed for precise row sowing of corn seeds on previously processed and prepared soils, provided the soil moisture is no more than 30%.

The vegetable seeder for the SI10 walk-behind tractor sows 1 row. Can be aggregated with walk-behind tractors, power from 6 hp.

The dosing mechanism is actuated from the axis of the support-drive wheel by means of a chain transmission consisting of a system of stars, a chain and a tension device. By changing the ratio of chain transmission, you can adjust the step of sowing seeds in a row.

The standard equipment of the planter SI10 includes one drum with a groove with a radius of 18 mm.(//tractor-service.com)

The design of the planter is adapted for sowing corn. But, when equipped with a sowing drum with a groove radius of 10 mm, you can sow other crops with large seed size: sunflower, soybean, pea, pod and bush bean.

Seed calibration is recommended to ensure uniformity of sowing. Some elite varieties have increased seed sizes. This must also be taken into account when choosing a dosing drum.

The design of the single-row vegetable planter economy SI10 allows you to adjust the depth of seed wrapping and the step of sowing in a row. Compared to other models of vegetable planters, the SI10 model lacks a clutch for disconnecting the drive, as well as a harrowing mechanism.

The seeder formotoblock is equipped with a naralnik (keel-shaped) coulter. Additional equipment with a row marker is also possible.
