Horizontal slicer for meat and fish STvega Meat Hor Slicer H16A, Kyiv

Horizontal slicer for meat and seafood STvega Meat Hor Slicer L16A is designed for slicing such products as meat, fish fillets, chicken fillet The machine is designed for slicing a product cooled to 0 °C.

Principle of operation:
The operator manually feeds the raw material onto the conveyor belt, which transports the product to the cutting area. The clamping mechanism reliably fixes the product, and the additional conveyor belt on top facilitates its movement through the moving blades. Horizontal blades carefully cut the meat into slices of a given thickness from 2.5 to 40 mm. Ready slices are transported by a conveyor to a container or sent for further processing if the machine is integrated into an automated line.

Equipment advantages:
• The cutting blades are very sharp, thanks to which it is possible to cut the product with a thickness of 2.5 mm.
• Multi-layer cutting with the possibility of thickness adjustment.
• An improved pressure control system of the pressure mechanism on the product, a combination of knife groups, as well as an ideal ratio of the speed of movement of the conveyor belt and cutting blades ensure the integrity of the product after cutting.
• There is a calendering function to achieve the required surface characteristics and shape, which is obtained with the help of a pressing mechanism and conveyor belts.
• Simultaneous cutting of several layers makes it possible to achieve uniform distribution of slices with extremely high stability.
• Thanks to the belt transmission and the absence of a chain and gearbox, the machine is characterized by stable operation, convenient operation, simple maintenance (quick disassembly and installation of the belt), as well as the absence of a dead corner for cleaning.
• It is possible to adjust the speed of the conveyor belt and the speed of the cutting blades in accordance with the various characteristics of the initial product and the requirements for the finished product.
• The inverter is imported from Germany, has protection against voltage drops to avoid burnout of electrical components and motor.

Characteristics:(//tractor-service.com)
Productivity: 120 pcs/min.
Dimensions: 1750*800*1300 mm
Slice thickness: 2.5–40 mm
Conveyor belt width: 160 mm
Maximum product width: 150 mm
Recommended product height: 40mm
Conveyor belt speed: 3–15 m/min.
Power: 0.95 kW
Case material: stainless steel SUS 304
