Heighted disk harrow Harvest 240 /Pallado 2400 Characteristics Brand Harvest Type, Dnepropetrovsk region.

Disk harrow mounted Harvest 240 /Pallado 2400
Characteristics
BrandHarvest
Harrow type Harrow
Gripping width, m 2.4
Working speed, km/h 12
Productivity, ha/h 2.88
Overall dimensions, mm 2050x2700x1200
Mass, kg 980
It is aggregated with tractors with a capacity of at least hp. 80(//tractor-service.com)
Processing depth, mm 100-140
Angle of attack of discs, degrees. 0...30
Number of cutting units, pcs. 18
Number of rows, pcs. 2
Distance between rows of disks, mm 950
Diameter of working bodies, mm 560
Distance between disc blades, mm 250
The Harvest 240 mounted disk harrow is intended for resource-saving pre-sowing soil treatment for sowing grain, technical and fodder crops, weed destruction and grinding of crop residues after harvesting crops, as well as grinding, leveling and compaction of soil after disking.

The Harvest 240 disk harrow is intended for use in soil and climatic conditions with soil moisture up to 27%, as well as in fields with a large amount of crop residues. Each disc of the harrow is installed on an individual stand, which allows the harrow to work in fields with a large amount of plant residues and weeds, excluding the winding of plant residues on the axis of the disc and clogging of the space between the discs, and also ensures high maintainability of the unit. The design of the unit provides smooth adjustment of the angle of attack of each row of disks within the range from 0° to 30°, which allows you to optimally adjust the harrow for different types of soil.
