Parallel driving system GPS navigation tractor Agro Slalom MTZ, Kharkiv region.

Parallel driving system based on GPS-navigation — technically perfect and economically beneficial technology for agricultural machines. It is especially effective to use these systems together with wide-grip units. With the help of satellite navigation systems, it is possible to drive both in a straight line and in a curved line, easily minimizing overlaps and underpasses between neighboring pens.

The system is intended for parallel driving of agricultural machinery. The system consists of an external GPS module for accurate positioning, combined with an antenna and a Bluetooth module, and an application for parallel driving for the Android operating system, which is installed on a mobile device (tablet, smartphone).

The GPS module is installed on the roof, or on thehood of the tractor (strictly along the central axis), it is fixed with the help of 4 neodymium magnets on the receiver body, it is powered from the tractor's on-board network in the voltage range from 4 to 30V. It connects to a mobile device via Bluetooth wireless technology. The tablet with the software is installed in the tractor, connected to the power supply through the cigarette lighter socket and the system is ready to work.

The accuracy of the system's operation, i.e. from passage to passage, with quality guidance, is 20-40 cm.

The software implements:

- high coordinate update speed (10 Hz);
- parallel driving along a straight and curved trajectory;
- perspective (3D) display of the workspace;(//tractor-service.com)
- import of pre-prepared fields;
- area measurement functions;
- functions for viewing processing results, exporting results;
- two adjustable color schemes for work in different lighting conditions (day-night);
- export of processing in KML format for viewing on Google maps and other.

2 variants of system configuration:
1. GPS module + program ASN-agro, AgroSlalom or others; 160
2. GPS модуль + программа + планшет (диагональ экрана от 7 дюймов), в комплект входит держатель на лобовое стекло, зарядное устройство от разъема прикуривателя.
The tablet can be fully used outside the tractor.

The price is indicated for the first configuration option.
I will send it by mail or install it directly on the unit.
