Polygonmach Vibrating feeders - Bunkers that are used to feed crushers on our stone crushing lines.

Vibrating feeders are installed before the maincrushers, primary impact crushers or jaw crushers in order to obtain the desired size and reduce the costs of intermediate crushers, to increase the productivity of the system, to achieve alignment in the equipment and improve uniform distribution.

Let's talk about some of the advantages of these bunkers;
Polygonmach vibration feeders make it possible to minimize the negative consequences of uneven and non-standard operation of crushing systems:

If there are sudden emissions and stagnation during the waiting time in the main crushers, during this time the conveyors and screens are overloaded with instant loads.
These reasons lead to difficulties in crushing the material in impact crushers, sand machines, cone crushers and crushers with a vertical shaft, and this can even lead to overheating of the equipment.

In addition, because of these sudden overloads, hammers and other working parts of the machine are affected, and work systems are overloaded. Consequently, wearing parts reduce efficiency by up to 60% and increase maintenance costs. That's not all. Wearable parts are not only internal parts of the car. More problems than expected arise from irregular crushing methods in the conveyor belt and equipment, in addition to belt breaks, wear on one side of the rollers, bearing breaks, drum shaft breaks, and others.

As long as these problems are present, it is impossible to achieve the desired efficiency with the help of non-standard screening. Consequently, feeders and intermediate hoppers are used to eliminate this fluctuation, to achieve quality, reduce maintenance costs, and increase the service life of machines and equipment.

Features of Polygonmach vibrating feeders and hoppers:
Smooth vibration, reliable operation, long service life, suitable for loading any material

TECHNICAL CHARACTERISTICS OF BUNKER MANUFACTURERS:

MODEL CPG - 09
Case size (mm) 4,600 x 1,100
Grizzly Length (mm) 1.400
Motor power (kW) 2 x 7.5
Hopper volume (m3) 15 - 20 - 30
Capacity (t/h) 200 - 300
Weight (kg) 18,000
(//tractor-service.com)
MODEL CPG - 10
Case size (mm) 3.000 x 85
Grizzly Length (mm) 1.160
Motor power (kW) 2 x 4
Hopper volume (m3) 10 - 15 - 20
Capacity (t/h) 150-200
Weight (kg) 12.000 MODEL CPG - 11
Body size (mm) 2,500 x 520
Grizzly Length (mm) 820
Motor power (kW) 2 x 3
Hopper volume (m3) 8
Capacity (t/h) 80-100
Weight (kg) 8,000

MODEL CPG - 13
Case size (mm) 1,370 x 4,880
Grizzly Length (mm) 1.840
Motor power (kW) 2 x 9.8
Hopper volume (m3) 30
Capacity (t/h) 350-500
Weight (kg) 26.000

The official representative of the manufacturer - the Turkish company Polygonmach offers high-quality equipment at minimal prices and convenient delivery conditions.
The official representative of the manufacturer offers minimum factory prices.
Delivery of equipment to any region or country.

The manufacturer carries out chief installation and personnel training.
To receive a commercial offer, please send a request to our e-mail.
