Original disc harrow mounted BDP 2.5, 2.1, 2, 4 trailed, Kharkiv region.

Originaldisc -mounted harrow BDP 2.5, 2.1, 2.8 Trailed disc harrow BDP -2.5 BDP only new BDP Harrows Disc harrow trailed BDP -2.1N, BDP -2.5N. They are especially effective when working on dry, hard soils and slopes because they do not move the soil in the transverse direction to the movement and work the harvest residues well into the soil.
The units work as follows: when moving across the field, the disc rotates and the forces of friction of the soil on the disc are minimal, which ensures high efficiency and significantly lower energy consumption during plowing and fuel economy compared to row plows. When in contact with the cleaning device, the soil evenly descends from the concave side of the discs, providing an even soil surface on the cultivated field and burying the crop residues in the soil. The presence of two rows of disks ensures intensive grinding of the soil. support rollers, the position of which is regulated with the help of a screw device, ensure the required depth of soil cultivation and crushing of lumps in the upper layer of the soil.(//tractor-service.com)
Also, in the design of the aggregates, it is possible to change the angle of attack of the discs depending on the type and humidity of the soil. Discs are made with an internal sharpening, which makes the aggregates work very efficiently when processing viscous, heavy soil, including chernozem, reduces the traction force and increases the stability during movement of the aggregate.
Notches indiscs, in combination with internal sharpening, ensure better crushing of layers and release the accumulation of plant residues in front of the disc.
