Terra3 Pro 400 continuous cultivation cultivator, Zaporizhzhia region.

Terra Pro 400 is a three-row cultivator on a spring rack with a planar tooth leveler and harrow, intended for preparing the soil for sowing agricultural crops and caring for crops in fields littered with plant and harvest residues. The cultivator can be used in all climatic zones of Ukraine on soils of different mechanical composition with hardness up to 1.6 MPa and humidity of 8-30%.
The well-thought-out design of all nodes makes working with it as simple and effective as possible. The arrangement of the working bodies in three rows ensures thorough continuous cultivation of the soil and ensures a mutual overlap of up to 4 centimeters between the rows of working bodies during processing, even taking into account the wear of the arrow paws during the cultivation process, a complete trimming of weeds is guaranteed.
The reinforced spring (C-shaped) rack is installed in 3 rows, in combination with a 310-millimeter-wide arrow paw, which guarantees optimal and very high-quality fine loosening at a depth of up to 12 cm.
Vertical lifting of the cultivator into the transport position occurs with the help of two hydraulic cylinders and ensures a quick transition from the transport position to the working position and vice versa.
Characteristics
BrandHarvest
TypeTrailed
Working width, m 4(//tractor-service.com)
Working speed, km/h 10-14
Productivity, ha/h 4.8
Overall dimensions, mm 4050x4875x1030
Mass, kg 1560
It is aggregated with tractors with a capacity of at least hp. 80
Processing depth, mm 0...120
Number of cutting units, pcs. 15
Number of rows, pcs. 3
