ИСМ-15 and ИСМ-20 Machines clean and calibrate grain with high accuracy, Kharkiv region.

ISM - impeller-separating machine;
TsOK - cyclone-sediment complex (a unit with one cyclone and two or three sediment chambers, designed to clean the air circulating in the separator from dust);
APO – pre-cleaning unit (recommended for heavily “clogged” seed material, works in tandem with ISM and SOK machines);
SOC - self-moving cleaning complex, five in one (replaces ZAV)

We present the March 2023 prices for all the company's products.
An individual consultation is possible, as well as trial work with your material before making a decision.
Clarify the terms of supply of equipment necessary for your farm by phone.

- ISM-5, cleaning 5t/h, calibration up to 3t/h, 0.2-0.55kW, 50Hz, weight 155 kg, dimensions l.2150/w.460/h.1750mm., 220V - c. 62,000 hryvnias, 380V - ts. UAH 65,000.;
- ISM-5 TsOK, cleaning 5t/h, calibration up to 3t/h, 0.2-0.55kW, 50Hz, weight 374kg, dimensions d.3200/w.1000/h.2000mm., 220V/380V - c. UAH 132,500; 170

- ІСМ-10, очистка 10т/год, калібрування до 5т/год, 0,2-0,75кВт, 50Гц,, вага 165кг., габарити д.2420/ш.460/в.1880мм., 220В - ц. 72000 грн., 380В - 75000 грн.;
- ISM-10 TsOK, cleaning 10t/h, calibration up to 5t/h, 0.2-0.75kW, 50Hz, weight 420kg, dimensions d.3400/w.1000/h.2100mm., 220V - c. UAH 97,000, 380 V - ts. 139400 hryvnias.;

- ISM-15, cleaning 15t/h, calibration up to 7t/h, 0.4-2.2kW, 380V, 50Hz, weight 337kg, dimensions d.2310/w.650/h.2400mm, c. UAH 125,000;
- ISM-15 TsOK, cleaning 15t/h, calibration up to 7t/h, 0.4-2.2kW, 380V, 50Hz, weight 685kg., dimensions d.4800/w.1150/h.2800mm.), c. 193500 UAH.;

- ISM-20, cleaning 20t/h, calibration up to 10t/h, 1.5-3kW, 380V, 50Hz, weight 355kg, dimensions d.2300/w.650/h.2400mm.), price: UAH 138,500;
- ISM-20 TsOK, cleaning 20t/h, calibration up to 10t/h, 1.5-3kW, 380V, 50Hz, weight 690kg, dimensions d.4800/w.1150/h.2800mm., c. UAH 206,800.;

- ISM-30, cleaning 30t/h, calibration up to 15t/h, 1.5-4.5kW, 380V, 50Hz, weight 360kg., dimensions d.2310/w.650/h.2400mm., c. UAH 149,700; 180
- ІСМ-30 ЦОК, очистка 30т/год, калібрування до 15т/год, 1,5-4,5кВт, 380В, 50Гц, вага 760кг., габарити д.4800/ш.1150/в.2800мм., ц. 225400 грн.;
- SOK-25 c. UAH 520,000.;
- SOK-30 c. UAH 530,000;
(//tractor-service.com)
- APO-5 (productivity 5 t/h) c. UAH 80,800.;
- APO-50 (productivity from 10 to 50 t/h) c. UAH 162,000.

Additional equipment:
- mosquito net bag for ISM-5, ISM-10, etc. UAH 600; 190
- комплект wheels for ISM-5, ISM-10, c. 700 UAH.;
- a connector for a 150mm pipe. for ISM-5, ISM-10 on 2 trays, c. 750 UAH.;
- a connector for a 150mm pipe. for ISM-5, ISM-10 on 3 trays, c. 850 hryvnias; 195
- об'єднувач під трубу 150мм. для ІСМ-5, ІСМ-10 на 4 лотка, ц. 960 грн.;
- U-shaped connector for ISM-5, ISM-10 for all trays (2,3,4), etc. 260 UAH.;
- net (sieve) up to APO-5 (6,8,10,12,14 mm. and more) c. 7080 UAH.;
- mesh (sieve) up to APO-50 (6,8,10,12,14 mm. and more) c. 13500 hryvnias; 199
- нанесення гумового шару на внутрішні стінки машини для захисту насіння бобових культур від розколу, ц. 2000 грн.;
- auger for ISM-5, ISM-10, ISM-5 Tsok, ISM-10 Tsok, c. UAH 51,200.

Video APO-5:
https://youtu.be/CqOwCpm8f8U
*
Video APO-50:
https://youtu.be/VkxC7yRTDyw
*
Video APO grain preliminary cleaning unit:
https://youtu.be/vdA2w1B1PcY
*
Video ISM-5Grain separator:
https://youtu.be/MuiW7pcM5vI
