KSU-4/ KSU-8 trailed tiller cultivator with roller, Dnipropetrovsk region.

High-quality wide-grip tillage cultivator with roller and spring harrows KSU-4/ KSU-8. The KSU continuous tillage cultivatortrailed is intended for continuous soil cultivation, as well as forpre-sowing processing. KPS4 solid cultivator, KPS8 solid cultivator, buy KSU cultivator in Ukraine.
Finishing is provided by a 3-row spring-tooth harrow and a rolling plate roller.
Processing with a KSU-8 cultivator in one pass, perform a set of necessary soil processing operations both during the main and pre-sowing cultivation (forcontinuous soil processing).
KSU-8/KSU-4 high-quality cultivator, easy to maintain and adjust, reliable design, high-quality wearable working parts with high service life, high productivity

TECHNICAL CHARACTERISTICS of the cultivator KSU-4
Trailer type
Working width of capture. m 4
Productivity. 4 -g/h
Depth of tillage. cm 5-15
Mass. kg 1100
Number of rows. piece 3
Number of working bodies. pc 16
Tractor class 1.4
The working body is a 330 mm flat-cut arrow foot on a parabolic spring stand, with a cross section of 20x45
Steel grade - 65 G.
Thickness - 8 mm(//tractor-service.com)

TECHNICAL CHARACTERISTICS of the cultivator KSU-8:
Type of Machine Semi-trailer
The depth of KPS-8 processing is 5-15 cm.
The length of the KPS-8 in the working position is 8000 mm.
The height of the KPS-8 in the working position is 2300 mm.
Type of working body KPS-8 - flat-cut arrow paw
The minimum distance between adjacent working bodies on the frame is 230 mm.
Working KPS-8 paw width 330 mm.
Overlap of KPS-8 legs 80 mm.
Standard KPS-8 equipment 3-row harrow with spring teeth
Mass of KPS-8 - 4000 kg.
Number of paws KPS-8 - 34 pieces
Steel grade - 65 G.
Thickness - 8 mm.

Warranty 1 hour! Delivery across Ukraine!
