Cultivator KSU(KPS)-8, 4 with roller and spring harrows - BEST OPTION, Kherson region.

Purchase of universal cultivator KSU (KPS) -continuous processing soil is an ideal solution if you have a farm. Cultivator KSU-8.4 has a lot of advantages and will certainly be useful to any farmer.

Cultivator KSU(KPS)-8.4 is intended for continuous soil cultivation, forpre-sowing processing, and also for loosening unprocessed stubble.
Processing with a cultivator in one pass, perform a set of necessary soil processing operations both during the main and during pre-sowing cultivation (for continuous soil processing). Guaranteed high-quality cultivation of the soil by the cultivator, reliability of the design, ease of maintenance and adjustment, high productivity, moderate prices for the cultivator and high-quality wearable working parts with a high service life are the key to timely performance of the necessary work with the highest quality and the best result.

The cultivator is designed according to the semi-trailer scheme and is aggregated with the tractor with the help of a height-adjustable long traction-coupling device of high stiffness, which allows to minimize the influence of the displacement of the trailer point when the tractor is moving, and also significantly increases the maneuverability of the "tractor-cultivator" unit when turning.

Cultivators with a working width of up to 8.4 meters are inclusively equipped with four single-axle wheeled mechanisms, with a working width of more than 10 meters - four mechanisms equipped with two-wheeled balancing carts with a center-axis base of 700 mm, which ensures maximum stability of the cultivator during operation and accurate processing to a given depth.

The working clearance of the cultivator (from the bottom of the frame to the sole of the foot) is 710 mm, which, together with the 4-row (grab width up to 8.4 meters inclusive) or 5-row (grab width over 10 meters) arrangement of working bodies with the smallest distance between adjacent ones in the row of 690 mm, completely eliminates clogging of the subframe space with harvest and plant residues. And with an intercenter distance of 230 mm between adjacent flat-cutting paws with a grip width of 310 mm (mutual overlap of 80 mm), 100% cutting of any weeds is ensured.

Technical characteristics of the cultivator
Type of machine Semi-trailer(//tractor-service.com)
Processing depth 5-15 cm.
The length in the working position is 8000 mm.
Height in working position 2300 mm.
The type of working body is a flat-cut arrow paw
The minimum distance between adjacent working bodies on the frame is 230 mm.
The working width of the paw is 310 mm.
Overlap of paws 80 mm.
Standard equipment 3-row harrow with spring teeth
Optional equipmentplastic skating rink with step ~100 mm. with a diameter of 255 mm.
The clearance under the frame (from the soles of the paws) is 700 mm.
The minimum distance between adjacent working bodies is 690 mm.

WE WORK WITHOUT PREPAYMENT. WE DELIVER TO YOUR HOUSE!
