Rowless high-speed harvester for harvesting sunflower ZhS from 4m to 12m, price, buy, Kherson region.

For harvesting sunflowers, the best harvester
UNICORN SUNFLOWER HARVEST
DISTINCTIVE FEATURES,
TECHNICAL IMPROVEMENTS AND IMPROVEMENTS
Delivery .+79900265592
FRAME: the improvement of the frame design allowed to increase it.
strength and stiffness. Corrected angles and mutual distances
arrangement of load-bearing beams and finger beam. Reinforced braids were tied.
the frame at critical points, thereby providing minimal static.
deflection of the frame as a whole. Many small pods are replaced by sheet parts.
of complex configuration, manufactured on a high-precision imported machine.
CNC equipment. This reduced the total number of welds, reducing
internal stresses from friction in frame elements.
SCREW: the design of the screw is reinforced with additional partitions, in
in the form of rolled plates, and elongated support coils. The auger is protected
with a safety friction clutch, which is installed on the spline.
of the shaft and limits the torque on the auger in the event of stones hitting и
other extraneous objects into the ego's work area, thereby protecting everything.
rotating parts from overloads and destroyed.
REEL: the weight of the reel is reduced by 70 kg. due to the use of the pipe
larger diameter, while its rigidity has increased. Long shafts
replaced with trunnions, which added strength to the structure and increased its life
exploitation The reel is equipped with feed fingers serving
for active cleaning of the working space between lifters from clogged
masses(//tractor-service.com)
From above, the auger is closed with shields with a diameter of 179
штампованных отверстий 3мм, которые
предотвращают переброс массы через шнек и
reel, and also serve to provide
safety of personnel in the process of work
Delivery +79900265592

Reapers for harvesting sunflowers This is a special equipment that was created with the help of innovative technical solutions in the field of agricultural machinery production. This model is distinguished by improved technical and operational indicators, reduced specific weight and a more affordable price compared to its predecessors.
* The harvester is intended for harvesting sunflower with a width of up to 11 meters.
* The design is equipped with two cardan shafts.
* Installation of the stretching shaft is designed under the beam, thanks to which the cut is made directly under the sunflower basket itself.
*Thanks to the presence of a closed circuit of square pipes, the longitudinal stiffness of the beams is ensured.

The most significant feature
Reapers have the following distinctive features:

Long stem lifters for 180 cm
Thanks to a reduced angle of attack of 5° (compared to 10° in analogues), optimal sunflower harvesting is ensured.
The presence of an adjustable clearance in the streams (30-65 mm) ensures the harvesting of the smallest sunflowers with minimal losses.
The use of special Schumacher guides and pressure rollers instead of plates reduced the friction of the knife strips to 2%, thanks to which the operating life of the device increased significantly. At the same time, the presence of double intermediate plates increased the stiffness of the knife edges.
Thanks to the use of new combs, the construction of the reels has become lighter by 50-80 kg and greater rigidity has been ensured.
Screws are also made with removable coils. The presence of additional removable coils of the spiral and removable galvanized pushers allows the use of harvesters for any known brands andmodels of combines.
A new bumper and a galvanized protective net protect the auger and reels, which prevents the loss of sunflowers.
The height of the bumper is adjustable from 18 to 45 cm, so it is possible to harvest sunflowers of any variety.
Warranty 24 months.
Delivery!+79900265592
