Seeder furrow hybrid Su-8m as Ups-8 precision seeding, Cherkasy region.

Seeder furrow hybrid Su-8m as Ups-8precise sowing has a number of advantages and is easy to operate, the seeder showed the best results in the speed and quality of sowing.
SUPN-8m (SU-8 hybrid) seeders are intended for precise sowing of calibrated seeds of corn, sunflower, castor, sorghum, soybeans, as well as seeds of fodder beans, beans, lupins with simultaneous application of granular mineral fertilizers separately from the seeds and rolling of the soil in the rows. Seeders provide sowing at the exact distance, excluding the use of manual labor when forming the required interval between plants.SUPN-8 creation discharge in the pneumatic system is provided by a fan.
The fan of the new sample (as on the UPS seeder) works directly from the power take-off shaft.
The HMSH motor is not used.
Planters are aggregated with YuMZ, MTZ-80/82, T-70S tractors.
A harrow is installed on the sowing disk, which prevents the compaction and suspension of seeds in the chamber of the sowing device.
An unloading hatch is provided in the bunker to remove the remains of mineral fertilizers.
It is possible to install an electronic seed sowing control system upon request.
The use of kapron bunkers significantly increases the unit's resistance to atmospheric influences.
Technical characteristics of the planter SUPN-8m (SU-8 HYBRID)
The type of machine is mounted
Width of capture 5.6
Number of rows 8
Width between rows 700
Working speed 2.5-9
Productivity 1.4-5.04
Capacity of bunkers (total)(//tractor-service.com)
– for seeds 150
– for fertilized 192
Sowing rates
– for seeds 2-57
– for fertilized 50-250
Depth of seeding 40-120
Overall dimensions of the seeder in the working position (without taking into account the departure of the markers)
length 1960±20
width 5740±60
height 1400±12
Ground clearance, mm, not less than 300
Dimensional dimensions of the seeder in the transport position
length 1960±20
width 6700±60
height Zb50±20
Mass 1278
It is aggregated with tractors with a capacity of 80.
