Water cooling radiator of the MF 38 combine harvester engine, Kyiv region.

Cooling radiatorharvester grain harvester
Radiator for water cooling of the MF 38 engine - VALMET 612 Radiator catalog number - D28780455
Technical data of the radiator
TU U 34.3- 13511529 – 001-2004
Radiator spacing – 6 Heat output – – 168.0 kW Radiator weight – – 54.0 kg Diameters of connecting pipes
1.– 57 mm 2.– 57 mm(//tractor-service.com)
Leak tested for 10 min.
air pressure – 1.5 Atm.
Resource 12000 motor hours WARRANTY 12 months Technical data cores
Honeycomb height – 780 mm Honeycomb width – 930 mm Honeycomb thickness – 114 mm Honeycomb spacing – 6 Honeycomb system – FFC Honeycomb material – copper brass
The Kaskad company recommends that you familiarize yourself with
with all our products.
The engine cooling radiator manufactured by Kaskad LLC is an analogue of the radiator widely used on special equipment. Our product uses a core made of a ribbed bimetallic tube and collectors made of steel. Technical parameters are developed according to TU U 34.3-13511529-001-2004 and are given in the table .Due to the introduction of innovative technologies, it was possible to achieve an acceptable price, while maintaining the high quality of production.
