Agd 2.5H trailed disc harrow, Dnipropetrovsk region.

Agd 2.5H trailed disc harrowDisk harrow trailed AGD harrow - 2.5H (patented) Agd 2.5H trailed harrowdisc harrow

Trailer type,

Construction width, m 2.5 minus 0.1
Productivity ha / time, 1.8...2.2
Depth of soil cultivation, cm 8...18
Working speed of movement, km/h 8.0...12.0
Transport speed, km/h 20
Weight of the product (without accessories), kg 1160 minus 50 Dimensions, mm, not more than 150
длина 4800 минус 150 (//tractor-service.com)
width 2800 minus 150
height 1000 minus 150
Ground clearance, mm, not less than 300
Guaranteed resource, 1240 ha.
Transfer to transport and working position hydraulic.
Options for using AGD-2, 5H:
- as a trailing unit, it is attached to the tractor with the help of a trailing device;
- as an intermediate option, half-mounted; 160
- как навесное орудие, прицепное устройство переставить в вертикальное положение,
disconnect the wheel travel, hang the unit on the three-pointtractor system;
A large selection of AGD-type disc harrows produced by ST VF "A G R O R E M M A S H"
Trailed disc harrows АГД-2.1Н, АГД-2.5Н, АГД-2.8Н, АГД-3.5Н, АГД-4.5Н
