ALL REAL BDF trailed harrow (p)-2.4 disc (wheels in the middle) for Mtz-82-892, Dnipropetrovsk region.

New traileddisc harrow harrowBDF-P-2.4 (mounted/trailed) Unmaintained working body of disc harrow GOS-compensation 25-40% N.D.S., Discbdf harrow 1.8-,2.1-, 2 4 mounted harrow (stand of a new model - NEOBSLUZHYVAEMYY BODY) two-track harrow BDF-2.4 Harrow BDF-2.4 two-track harrow with frontal arrangement of individual housings of disc working bodies Unit BDF-2,4 disc mounted harrow with frontal arrangement of working bodies. The harrow is intended for continuous and pre-sowing soil processing of various mechanical composition for technical, grain and fodder crops and with grinding and embedding of plant residues in the soil (refreshing of sodden meadows) in various agrotechnical schemes.

Working width, m 2.4
Productivity, ha/h 2.2
Processing depth, cm 8-20
Working speed, km/h 9-12
Disc diameter, mm 650(//tractor-service.com)
Mass, kg 1400
Tractor power, hp 80

The adjustable processing depth is approximately 8 to 18 cm.
The harrow contains two rows of disks, each of which is located on an individual stand, which is attached to the bar with two L-shaped brackets (diameter 20 mm). This design excludes clogging of the interdisk space. The harrow can be used in all soil and climatic zones where the soil moisture does not exceed 27 percent and the soil hardness does not exceed 3.5 MPa, and it is also not recommended to use this harrow in areas with significant stony inclusions. Due to the use of individual racks in the design, the front harrow can be used at high working speeds - up to 14 km/h.
This harrow uses camomile discs (cut-out spherical) with a diameter O of 650 mm, a thickness of 6 mm, made of steel grade 65G.
During manufacture, the discs are thermally treated, which ensures a hardness of 38-46 HRC.
Disks are installed on hubs that rotate around the axis on roller bearing assemblies at an angle of attack of 21 degrees and a vertical inclination of 21 degrees.
