SZF-5400 (SZ-5,4) grain seeder
The SZF-5400 seeder is intended for regular sowing ofgrain seeds, leguminous crops with simultaneous application of mineral fertilizers.
Advantages of SZF-5,4:
- the central bar of the frame is strengthened, it eliminates the deflection of the unit;
- the volume of the bunker is increased to 1.5 tons.
- a coulter with an offset is installed - it excludes clogging of coulters with weeds and harvest residues.
To order, the planters are equipped with a transport device.
The seeder is equipped with various coulters and sets of sealing working bodies, thanks to which it can be converted from one version to another in the conditions of the farm.
SZF 5.4 — intended for row sowing, equipped with two-disc coulters and finger wrappers;
SZF 5.4-04 — for row sowing, equipped with two-disc two-row coulters, finger wrappers;
SZF 5.4-06 — for row sowing, equipped with two-disc single-row coulters and rollerrollers.(//tractor-service.com)
SZF 5.4; SZF 5.4-06; (SZF 5,4-04)
Width of capture m, 5.4
Number of lines, pcs. 36; (72)
Row width, cm 15; (7,5)
The depth of planting seeds and fertilized, mm 40-80; (30-80)
Overall dimensions (length x width x height), mm 2950x6750x2750
Mass, kg 2554±100; 2803±100; (2804±100)
It is aggregated with tractors with power, hp. to 85
Delivery Warranty.
