Trailed roller harvester ZhVP-4, 9, Zaporizhzhia region.

Trailed roller harvester ZhVP-4.9 for MTZ, YUMZ, T-40 tractors is intended for mowing of grain, grain, leguminous and grain crops, with stacking of the mown mass, in a single counter-flow windrow in all climatic zones of their cultivation.

Distinguishing featuresZhVP-4,9 harvesters from similar ZHVP-4, 9 harvesters produced earlier:

The ZhVP-4 9 harvester is equipped with anew universal, springless anti-winding reel with a two-sided mechanism for tilting the rakes. Its reliable operation and the quality of the technological process depend on the correct assembly and installation of the reel on the ZhVP-4 9 harvester.

Transportation of the ZhVP-4 9 harvester is carried out by a tractor, while the ZhVP-4 9 harvester is transported as a trolley, which reduces the load on the tractor hitch, the frame of the ZhVP-4 9 harvester and excludes deformation and destruction of the ZhVP-4 9 harvester units during transportation.

The kinematic scheme of the drive of the transmission shaft has been changed, which eliminates the twisting of the belt transmission, compared to old models, which in turn increases the service life of the belt.

The design of the conveyor shafts has been changed with the use of spherical bearings, which prevents jamming of the shafts during misalignment, as a result of which the service life of the bearings increases.

Improved conveyor belt drive scheme. A new conveyor drive scheme is used when the lower branch of the conveyor belt is tensioned, which prevents the conveyor belts from breaking and reduces the noise during harvester operation.

Improved access to the transmission shaft, which facilitates its maintenance and makes it possible to immediately detect and eliminate the slightest malfunction.

Changes were made to the design of the frame and nose, which increased the strength, productivity of the ZhVP-4.9 harvester, and its maintainability.(//tractor-service.com)

The left side of the ZhVP-4.9 harvester is reinforced, which prevents its deformation.

Reinforced platform of the crank shaft, which completely excludes the destruction of this unit.

The ZhVP-4 9 harvester can be equipped with a Shumaher-type cutting device.

Technical characteristics:
width of capture - 4.9 m
productivity - up to 4 ha/h
aggregated with tractors - MTZ-80/82, YuMZ, T-40
mass - 1545 kg

The ZhVP-4.9 harvester is simple and reliable!

The product is certified!

Factory warranty! Quality! Delivery to the household
