Spare parts for the ZL40/50 gearbox, spare parts for the ZL40/50 gearbox of the ZL50G loader, SEM, Petronik, Kyiv

Spare parts for the ZL40/50 gearbox, spare parts for the ZL40/50 gearbox of the ZL50G loader, SEM, Petronik, Foton, TOTA, LW541 XZ656 XG955

9F20-230000 Hydraulic transformer
402222 Hubwheels
GB3452.1-82 Ring Ø128x3.55
402216 Body
402221 Sealing
402220 Gear
GB276-89 Bearing 117(130x85x22)
402224 Adjustment gasket
402226 Clamping plate
402218 Lock washer
GB5783-86 Bolt M8x30
402225 Oil reflector
402217 Stator disk
GB894.1-86 Retaining ring 80
402209 Turbine wheel of the first stage
402212-213 Turbine wheel of the second stage
1402238 Grooved seal
GB893.1-86 Locking ring 50
GB276-89 Bearing 113(100x65x18)
402206 Turbine hubfirst wheel steps
402207 Turbine wheel cover of the first stage
GB276-89 Bearing 210(90x50x20)
402208 Elastic pin
402236
402203 Ring
Casing wheel
402210 Fastening ring
402202 Elastic plate S=1.0
GB5782-86 Bolt M12x30
402211 Paper gasket
403700 Transmission control valve
ZL40-ZD Gasket
402111C
402111 402111X Fitting
402106 Gasket
403005A Transmission housing
GB276-89 Bearing 211 (55x100x21)
403057 Bearing sleeve
403058 Sealing
403001 Sealing
403002 Cover
GB5783-86 Bolt M10x30
403022 Pin
403005 Transmission housing
403055 Drive shaftsteering pump
GB1096-79 Key 14x35
403056 Steering pump drive gear
GB277-89 Bearing 50210(50x90x20)
GB894.1-86 Retaining ring 90
GB276-89 Bearing 112 (60x95x18)
403610A Gear shaft
403021 Sealing
GB119-86 Pin A10x30
403400 Oil tray
GB93-87 Washer 10
GB5783-86 Bolt M10x25
403200 Coupling
GB93-87 Washer 14
403003A Intermediate cover
403004 First gear cylinder
403023 Fixing bar
GB1235-76 Ring 20x2.4
403006A+403010A Outer ring seal
403010A Inner ring seal
403008A First gear piston
403222 Toothed clutch 1st gear
403012-013 Drive discs 1 and rear gear
403011 Driven discs 1 and rear gear
GB5783-86 Bolt M10x30
GB93-87 Washer 10
403225 Connecting disk of direct transmission
GB894.1-86 Retaining ring 90
GB277-89 Bearing 50210(50x90x20)
403226 Sun gear
403224 Pressure disk
403223 Carrier of the first planetary transmission
403220 Locking ring
403216 Toothed clutch of transmission with/x
403014-15 Friction clutch housing with carrier
403213 Reverse gear carrier
403215 Lock washer
GB93-87 Washer 8
GB5783-86 Bolt M8x14(//tractor-service.com)
403020A Internal sealing ring
403018A Reverse gear piston
GB276-89 Bearing 110(50x80x16)
403227 Here is satellite 1 transmission
403217 Gasket
403219 Spacer
GB309-84 Needle bearing
403218 Satellite
403016 Spring guide
403017 Spring
403221 Here is the reverse gear satellite
403101 Sealing 70x78x5
GB276-89 Bearing 116(80x125x22)
403103 Second-stage gear drive
403102 Sealing 45x53x5
GB301-84 Thrust bearing 8111
403104 Input shaft of the first stage gear
GB276-89 Bearing 311(55x120x29)
403105 Adjustment ring
403207A Roller Ф15x32
403204A Spring
403202A Spring saddle
GB276-89 Bearing 211(55x100x21)
403203 Intermediate input shaft
GB276-89 Bearing 110(50x80x16)
403210 Spacer sleeve
03205A Left ball retaining ring
403209 Internal cam wheel
403206 The right ring that holds balls
403208A Gear wheel
GB276-89 Bearing 210(50x90x20)
403211 Adjusting ring
403212 Adjustment ring
GB276-89 Bearing 122(110x170x28)
403504 Pin
403501 Pressing disc of direct transmission
403505-506A Direct Drive Drive Disc
403502 Direct transmission shaft
403509 Second gear
403507 Driven drive of direct transmission
GB276-89 Bearing 204(20x47x14)
GB894.1-87 Retaining ring 65
403513 Disc spring
403508-510A Direct drive piston
403516 Pin F10
403101 Sealing 70x78x5
403512A Direct drive clutch cylinder housing
403511 Intermediate output gear
GB276-89 Bearing 311(55x120x29)
403102 Sealing 45x53x5
403105 Adjustment ring
403301B Flange
GB1235-76 Ring 130x5.7
403304A Sealing saddle
JB2600-80 Seal SG70x95x12
GB893.1-86 Lock ring 130
GB276-89 Bearing 312(60x130x31)
JB2600-80 Seal SD25x40x10
403306A Traction of front and rear axles
403309 Rear output shaft
403308 Spring
GB308-89 Ball 10
403310 Movable sleeve
403307 Fork of the front and rear axles
403311 Output shaft gear
403312B-313 Front output shaft
403305A Spacer bushing
403304A Sealing saddle
403406 Gasket
403403-404 Filter screen
403408 Permanent magnet
403405 Support bar
GB93-87 Washer 6
GB5783-86 Bolt M6x25
402223 Plug ZG3/4"
403401-402-410-412 Oil pan housing
GB/T5785-2000 Bolt M12xl.5x40-10.9
GB/T889.2-2000 Nut M12x1.5
F20-251000 Intermediate fastening of the cardan shaft
F20-252000 Intermediate splined shaft
GB/T5786-2000 Bolt M12xl.25x30-10.9
F20-250001 Stop bar
F10-253000 Rear gimbal
GB/T93-1987 Washer 12
GB/T97.1-2002 Washer 12
GB/T5783-2000 Bolt M12x35
