Seeder UPS 8/ UPS 8-02, Kharkiv region.

UPS-8 furrow seederprecise sowing with sowing section equipped with 2 contour drives of a new design intended for dotted sowing of calibrated and uncalibrated seeds, sowing of uncalibrated seeds, but in in this case, the accuracy will directly depend on the size and degree of damage of the seed material.Precise seed drills ensure sowing at the final density, excluding the use of manual labor when forming the required interval between plants.
Pneumatic seeding devices of precision sowing seeders reduce the percentage of seed crushing by 10 times compared to mechanical ones.
All drive shafts ofgrain and fat seeding devices are mounted on rolling bearings. Indicators

UPS 8
Machine type

hinged
Width of capture
m
5.6
Number of lines
pcs.
8
Width between rows
mm
450, 600, 700, 900
450x900, 600x1200
Working speed
km/h
3.6-9
Productivity
ha/h
2-5.04
Hopper capacity (total)
dm3

- for seeds
 (//tractor-service.com)
200
- for fertilized

192
Sowing norms

for seeds
pc/p.m.
2-43
- for fertilized
kg/ha
50-250
Seed embedment depth
mm
40-120
Габаритные размеры
mm

- in working position

1700x6250x1430
- in transport position

6800x2300x3010
Mass.
kg
1278±3%
It is aggregated with tractors
hp (ts)
80 (1,4)
