Power: 105 hp.
Number of cylinders: 4
Forward/reverse gearbox: 12/12
Mass: 4000 kg
Complete set: ZIP
Warranty: 12 months.
Delivery
Free Shipping
Discount for self-delivery 1500 hryvnias
Calculation
In cash
Non-cash settlement
Credit
Warranty
Official warranty from the manufacturer
Returns
14 days to return the product without any questions.
Complete set
Oil (engine, gearbox, hydraulics)
ZIP
Toolkit
Operation manual
(//tractor-service.com)
Technical characteristics
Engine power, hp (kW): 105 (77.2)
Wheel formula: 4x4
Engine type: diesel, 4-stroke, HUAFENG R4105IZT24
Number and location of cylinders: 4, vertical
Engine starting system: electric starter
Cooling system: liquid, closed, with forced circulation of cooling liquid
Engine volume, cm3: 4650
Nominal traction force, kN: 24
Gearbox (CP): 12+12
Rear differential lock: +
Clutch: dry 2-disk permanently closed type
Main transmission: direct
Steering control: hydraulic
brakes: on the secondary shaft of the gearbox, brake drums
Power take-off shaft (PTO): rear, splined
Type
hydraulic pump system: gear pump (NSH) for the suspension drive / NSH for power steering operation
Load capacity of the hinged, kN: ≥17.2
Revolutions of the power take-off shaft (PTO), rpm: 540/1000
Size
tires: front 11.2-24, rear 16.9-30
Wheel track: front 1275-1400, rear 1270-1536
Agrotechnical clearance, mm: 535
Number of hydraulic outlets: 4
Trailer connector (socket): +
Compressor: +
Dimensions LxWxH mm: 3970x1710x2615
Curb mass, kg: 4000
