Air-water heat pump 180 sq.m. heating area up to 2500 sq.m., Kyiv

Check availability. (067) 466 - 26 - 03, (099) 452 - 41 - 03

The EVI heat pump is designed for heating/cooling and hot water supply of public and industrial facilities. The operating temperature regime of the heat pump is from 25C to 43C.
EVI Scroll compressor COPELAND - 4pcs;
Axial fans - 2 pcs.
Controller with microprocessor and touch screen;
Heat exchanger type Tube in shell;
Add. plate heat exchangers - economizers 4 pcs.;(//tractor-service.com)
Electronic expansion valve EEV 4pcs;
Channel relay;
Auto - defrosting system;
Protection against phase sequence error, voltage drops, increased / decreased pressure and temperature of refrigerant and water;
Control of circulation pump, room thermostat;
Programs on - off;
Control port via the Internet using the MODBUS protocol
Country of manufacture: China Cooling capacity 150 kW Refrigerant used R410a Minimum ambient temperature - 25 degrees. The payback period is 1 year. The maximum ambient temperature is 43 degrees. Type of heat pumpAir - waterElectric power42.3 kWHeat power 185 kWVoltage 380 VManufacturer TEPLOMIRMaximum heating temperature 60 °СConversion coefficient4.37Maximum coolant supply temperature60 °СNumber of modules4 pcs. Current 100 A Mode of operation Heating / cooling Warranty period 18 months Noise level 69 dB User characteristics Heating area 2500 m. Payback compared to centralized heating is one season.
