Grain Tire of the trailer Szap8551-02 new, Dnipropetrovsk region

Auto-Avtospice-Ukraine Ukrainian Agricultural Producer for the Collection and Transportation of Cereas Harvest Made for Agrarians trailer with a dump truck with a reinforced platform of the SZAP 8551-02. Internal dimensions of the platform, mm
Внутрішні розміри платформи, мм
Length 6000
Width 2440
Height with overhead sides of 1550
Габаритні розміри, мм
Length 7993
Width 2550
Height with overheads 2950
Specifications
The height of the scoop of the scoop is 940mm.
Weight, kg
A load carried 10600
Equipped trailer 5400
Full 16000
Square (M2) 14,5 (// tractor-service.com)
= Volume (M3) 22.7
Base (mm) 3800
Loading height, (mm) 1450
Track (mm) 1850
Road clearance (clearance) (mm) 378
Number of axes/wheels 2/8+1
wheels= 7.0-20
tires ||umber= 260R508 (9.00R20)
Поворотний пристрій кулькове однорядне коло
Rama welded, with two spars from two -to -cut cross -sections made of high -strength steel
Suspension Spoor
Sleeping on the sides: the angle of lifting the platform 45 ° back: the angle of lifting the platform 30 ° front board: solid, deaf. Lateral boards: on each side there are solid sides - the late side - folding with the possibility of variable fixation, both from the upper and lower hunger; -The topchny board - a sloping back sideboard: - solid, folding with an upper hunger. Hydraulic cylinder: Penta or Hyva 5 rod
Drum brakes
Working drum with a pneumatic drive made under a two -wire system with ABS
Parking spring energy accumulator
Electrical equipment Single-wire DC system 24V
