Disk trailed harrow AGD-2.1N. Bila Tserkva. On the AGD-2.1H harrow, the
discs are mounted on individual stands with a diameter of 660 mm, which makes it possible to adjust the angle of attack in 6 positions, which in turn allows you to qualitatively adjust the disc harrow for work in the field.
The trailed disc harrow AGD-2.1H is intended for plowing fields with grinding and placing plant residues in the soil, as well as pre-sowing soil preparation.
Trailed disk harrow AGD-2.1N is designed to work with tractors of the 14 kN (1.4 ts) class.
The AGD-2.1H trailed disc harrow can be operated in all soil and climatic zones.
Technical characteristics of the AGD-2.1H trailed disk harrow :
Width of capture, m 2.1
Productivity, ha 1.5 - 1.8
The depth of soil treatment cm 8 - 18
Weight of the product (without protective equipment), kg 1050
(//tractor-service.com)
Speed of movement, km/h 8 - 12
Tractor with which MTZ is Aggregated - 80/82/100/102
Overall dimensions, mm (length/width/height) 4800/2800/1300
Options for using AGD-2.1H:
- as a towed unit, which is attached to the tractor with the help of a towing device;
- as an intermediate option, semi-mounted;
- as a mounted weapon, the towing device should be rearranged in a vertical position,
disconnect the wheel drive, hang the unit on the tractor's three-point system;
