Membrane cloth MBS (thickness.0.8-2.5mm) TU U.600152253.024-2001
MBS rubber fabric (thickness 3-6 mm)
Membrane cloth MBS thickness (0.2 0.4, 0.6, 0.8, 1.0, 1.2, 1.5, 2.0, 2.5 mm)
Rubber fabric MBS (2.0, 3.0 4.0 5.0 6.0 mm) TMKSH ( 3.0 4.0 5.0 6.0 8.0 10 mm)
Membrane cloth is a rubber-technical product that is in demand for the production of flat membranes in a wide variety of machines and devices. These are gas pumps, car carburetors. Membrane fabric is made by rubberizing the fabric, which is performed by spreading or calendering, but with mandatory impregnation, which is done beforehand. Temperature indicators during operation range from + 150 to -50 degrees, while maintaining the quality indicators inherent in this product: elasticity, flexibility, wear resistance.
· The fabric is intended for the production of parts that work as diaphragms of vacuum regulators of distributors in the environment of automobile
gasoline,
natural gas and others.
· Material: single-layer kapron with two-sided rubber coating.
· Operating temperature range, oC: -40 to +100
(//tractor-service.com)
· Width, mm: 900 and 1000
Thickness, mm: 0.2; 0.4; 0.6; 0.8; 1.0; 1,2; 1.5; 2.0; 2.5
· Roll length, m 2: 15-20; 20-30;
· Short-term static load on a sample with a diameter of 190+20 mm b/w - 4.00 kgf/cm
The fabric is air-tight at a pressure of 1.5 kgf/cm,
The change in the mass of the canvas when exposed to the standard medium (isooctane-toluene 7:3) should not exceed 20%.
The warranty period of storage is 2 years.
"
