NEW TREND OF 2021! UPS-8M-03 precision seeder with cross-section support wheels, Dnipropetrovsk region.

We keep up with the times! And today we offer you to pay attention to the NEW TREND of 2021 - this is aPrecise sowing planter UPS-8M-03 with an intersectional arrangement of support-drive wheelsколесами. Their arrangement makes it possible to adhere more precisely to the necessary depth of planting seeds and avoid sifting..
- The seeder minimizes the risk of breakage during sowing and improves the quality of sowing as much as possible;
- Two-circuit drive of sections;
- Drive sections through a hexagonal shaft;
- Hydrogenated marker system;
- Fat bunkers of increased strength;
- Reinforced frame;

The universal pneumatic seeder UPS-8M-03 is intended for accurate sowing of calibrated seeds of corn, sunflower, sorghum, soybeans, as well as seeds of fodder beans, beans, lupins with simultaneous, separate application of granular mineral fertilizers and rolling of the soil in rows.
Precise seed drills ensure sowing to the final density, excluding the use of manual of work when forming the required interval between plants.
Pneumatic sowing devices of precision seed drills reduce seed crushing by 10 times compared to mechanical ones. The seed drills are equipped with a durable hydro-treated marker with an enlarged disk, which has the ability to change the angle of attack to obtain a clearly visible trace. The UPS-8M-03 precision seed drill is equipped with a centrifugal fan driven by a tractor PTO (540 rpm).
A damper is used to regulate the vacuum of the air flow on the fan. The fan is equipped with an overrunning clutch that protects the belt transmission from increased wear.
The beam of the seeder frame acts as a receiver, ensures the same vacuum in all seeding devices and eliminates the pulsation of the air flow.

The amount of seeds, which falls from the hopper into the sowing chamber, is regulated by the shutter. The presence of an inspection window allows visual control of the quality of the seeding device during the adjustment process.
An unloading hatch is provided for quick removal of seeds from the chamber of the sowing apparatus.
The fat-seeding system through the fat coulters provides the possibility of applying mineral fertilizers outside of the deadline, and eliminates the harmful effect of fat on the seeds.(//tractor-service.com)

Type of unit in the spring.
The number of lines pcs. 8
Width between rows cm 45, 70
Working speed km/h 2.5-9
Productivity ha/h 1.4-5.1
Capacity of bunkers (total)
- for seeds l 150 200
- for fertilized l 192
Sowing rate
- for seeds pc/p.m. 2-42
- for fertilized kg/ha 50-250
The depth of seed sealing mm 40-120
Overall dimensions
- in working position mm 1700x6250x1430
- in transport position mm 6800x2300x3010
Mass 1278
It is aggregated with tractors hp. 80
