Pneumosorting tables SP-30/120/200/300 are designed for cleaning difficult-to-separate impurities that differ from the main crop in specific weight, shape and surface properties. It is used for cleaning and calibration of
cereal seeds,
legumes, perennial herbs and other crops to bring them to high quality standards.
The pneumatic bridge can be supplied both as part of the line and as a separate machine. Installation of the machine does not cause difficulties, since only one power cable is needed for the built-in control panel. All internal power consumers are pre-mounted and combine the sieve drive, fan drive, starters, fuses and cable for the external control panel of the pneumatic table.
The main working units of the pneumatic sorting table are: a bed, fans, a receiving hopper (completed on request), a vibrating frame with a working surface (table), mechanisms for adjusting the transverse and longitudinal angles of the table, a drive and an air flow regulator.
The name of the joint venture is 200
Productivity per hour of the main time at bulk density
wheat not less than 750 kg / m3., t/h 6.8
Working area of the table surface, m2 4.1
(//tractor-service.com)
Number of fans, pcs. 5
The maximum performance of fans, m3 / h 8,000
Installed capacity of fans, kW / h 11.0
The installed power of the table drive, kW / h 1.1
Length, mm 3 292
Width, mm 1,862
Height, mm 1,992
Mass, kg 1,550
Price, $ 26,500 22,500
