VSI impact crushers with vertical shaft Polygonmach Turkey, Kyiv

Polygonmach impact crushers with a vertical shaft are also known as machines for the production of sand and are used as a tertiary crusher for obtaining a high ratio of fine-grained material and giving a cubic shape to products that pass through secondary crushers. Any types of materials, especially hard stones, such as basalt and granite with a maximum size of 45 mm, which are crushed by secondarycrushers, are fed into impact crushers with a vertical shaft.

Features of the Polygonmach VSI crusher:
Four replaceable crushing chambers allow changing the type of material and product characteristics.
An impeller or a rotor with variable speed allows you to change the type of material and technical characteristics of the product.
High reduction ratio Large symmetrical feed box
Four replaceable crushing chambers allow changing material sizes and tonnage requirements.
A variable speed impeller or rotor allows you to change the feed rates and tonnage requirements.
Cover lifting and additional anvil replacement system.
ARS and patented removable top tub make it easy to move the anvil ring and change the anvil.
Working elements and anvils with a high chrome impeller or a rotor with protection against stones and shelves for material. Reinforced roller bearings. Autonomous lubrication system.

Technical parameters:

MODEL VSI 900 - OR
Rotor diameter (mm) 975
Max. Loading size (mm) 90
Motor power (kW) 2 x 200
Capacity (t/h)
45 m/s 300
52 m/s 250

MODEL VSI 900 - CR
Rotor diameter (mm) 900
Max. Loading size (mm) 45
Motor power (kW) 2 x 185
Capacity (t/h)(//tractor-service.com)
45 m/s 450
52 m/s 375
58 m/s 320
60 m/s 300

MODEL VSI 800 - CR
Rotor diameter (mm) 900
Max. Loading size (mm) 40
Motor power (kW) 2 x 160
Capacity (t/h)
45 m/s 250 52 m/s
230 58 m/s 205
60 m/s 190

MODEL VSI 700 - CR
Rotor diameter (mm) 700
Max. Loading size (mm) 35
Motor power (kW) 115
Capacity (t/h)
45 m/s 90
52 m/s 85
58 m/s 70
60 m/s 65

The official representative of the manufacturer - the Turkish company Polygonmach offers high-quality equipment at minimal prices and convenient delivery conditions.
The official representative of the manufacturer offers minimum factory prices.
Delivery of equipment to any region or country. The manufacturer carries out chief installation and personnel training.
To receive a commercial offer, please send a request to our e-mail.
