Hydroraspredelitel MRS 70.4/1.RM.111, Kharkov region.

Hydroraspredelitel MRS70.4 / 1РМ111 ontractor MTZ without hydraulic lift

Description

Sectional hydrodistributor MRS70 is a complete analogue of RP70 of Belarusian production.

Hydrodistributors MRS70 are intended for changing the direction of the flow of the working fluid and protection from ot

MRC70 hydraulic distributors are designed to change the direction of the working fluid flow and protect against overloads in the hydraulic systems of tractors, agricultural, construction, municipal machines, road machines and other mobile machinery.

APPLICABILITY:

1. MPS70.4 / 1.РМ.111 (890) is an analogue of РП70-890 and is used on tractors without a power regulator and without a hydraulic lift ("Belarus" - 100X; 80.1; 82.1; 826; 82Р; MTZ-80X).

2. MRS70.4 / 2.РМ.111 (1221) are an analogue of РП70-1221 and are used to equip tractors with a hydraulic lift ("Belarus"-826; 806; 1021; 1022; 1026; 1221; 952).

Technical characteristics of MRS70:(//tractor-service.com)

Distributor type - Sectional, with an open center
Pressure, MPa:
nominal - 16
maximum - 20

Conditional passage, mm - 12
Consumption of working fluid, l / min.:
nominal - 70
maximum - 90

Safety valve type - Direct acting

Spool control - Manual
Number of spools: Determined by the number of sections from 1 to 10.
Positions of the spool - "Lift", "Neutral", "Lower", "Floating"
