Tractor mower finger KTP-2, 1 m, Zaporizhskaya oblast.

Appointment of the mower:
The 2.1 finger tractor mower is intended for mowing sown and natural grasses with the laying of the mowed mass in the bedding.
It is used in all soil and climatic zones.
The mower is aggregated with MTZ-80/82 tractors; YuMZ-6L/6M; T-25; T-40 and is hung directly on the hitch devicetractor.
Additional photo on the site oylenergomash.com.ua

The KPO 2.1-finger single-bar mower is intended for mowing sown and natural grasses in the ground. Mower is aggregated with YMZ-6, MTZ-80 tractors
Technical characteristics
Name Meaning Ed. change.
The width of the capture is 2.1 m.
Working speed up to 12 km/h
Transport speed 20 km/h
Productivity 2.5 ha/h
The minimum cutting height is 50 mm(//tractor-service.com)
The number of double strokes of the knife is 540 dv.h/min.
Weight 250 kg
Type of drive Crank and connecting rod drive (KSHP)

Device and operation of the mower
The mower is driven by cardan transmission from the power take-off shaft (PTO) of the tractor to the power take-off shaft 8 (PTO) of the mower. The two-arm drive pulley 3, rigidly connected to the VPM, transmits rotation to the shaft of the driven pulley through V-belts. An eccentric rigidly attached to the shaft of the driven pulley converts the rotary movement of the shaft into a reciprocating motion of the knife of the cutting apparatus through the connecting rod.
The technological process of mowing proceeds as follows: when moving a tractor with a mountedmower across the field, the grass falling between the segments of the moving knife and the counter-cutting edges of the finger inserts is cut. The cut plants are rolled through the cutting apparatus and placed on the surface of the field. At the same time, the stem diverter on the inner ski diverts the cut grass from the knife head slightly to the right, and the stem diverter installed on the outer divider diverts the cut grass to the left, providing free passage for the inner ski on the next run.
Also, the bar is equipped with the best device in terms of inertial effort cut quality, cutting power consumption and total load on the blades of the segments, as well as operational reliability is a cutting device with a stamp-welded finger, with four inserts, while the knife segments alternate with a notch up and down. This cutting device does not require daily adjustment of the gaps between clamps and segments. The segment is not wiped with a clamp. The high-quality cut of both upright stems and reclining stems, as the process of cutting inclined stems is facilitated if the stems are cut with a knife with the sharpening edge of the blade at the bottom, that is, an inverted segment. At the same time, clogging of the cutting apparatus is reduced. The costs of repairing die-welded fingers are reduced by equipping them with replaceable anti-cutting plates H 006.56.
All production is certified by the State Committee for Standardization, Metrology and Certification.
