Система замера поля AGRICOURSE MF CONTROL PRO, Запорожская обл.

BASIC POSSIBILITIES OF THE FIELD MEASUREMENT SYSTEM AGRICOURSE MF CONTROL PRO:

Measurement of the field area of any size and shape.
Distance measurement.
Saving the fields after the measurement in the device's memory. Ability to view information and maps of any field.
View fields on a computer when connecting the device via a USB cable.
Printout of fields on paper media via computer.
View fields on various applications (Google Maps, etc.).
Quick area measurement in automatic mode.
Area measurement in manual mode with increased accuracy and the ability to bypass obstacles (up to 0.2% error).

In order to determine the area of a field or any area, it is necessary to go around its perimeter with the device turned on in the measurement mode. If the area is large, you can use a vehicle. In this case, you need to move at a speed of no more than 20 km/h.

After the plot has been measured, the map of the field with its characteristics is entered into the device's memory. The name of the field is set before the measurement. For convenience, it is advisable to write down the sown crop, the date of the last treatment, the serial number and the location of the plot.

All saved fields can be viewed on the device display, or when connected to a computer. It is also possible to print a map of the field with the help of special software, which is supplied on the disc in the kit. When working with Agricourse MF Control PRO, it is advisable to use the stylus that comes with the device.

SOFTWARE AND HARDWARE CHARACTERISTICS OF AGRICOURSE MF CONTROL PRO:

— a modern processor with a basic clock frequency of 800 MHz,

— RAM 128 MB,

— connector for connecting memory cards,(//tractor-service.com)

— WINDOWS operating system,

— the screen diagonal is 4.5 inches,

— audio output for connecting external headsets,

— internal battery for autonomous operation (lithium-ion),

— autonomous operation in standby mode up to 200 hours,

— autonomous operation in navigation mode up to 3 hours,

— the maximum number of connected satellites is 20.

— built-in GPS antenna.

DELIVERY SET:

Field measurement system Agricourse MF Control PRO.
Reinforced fastening for a vehicle.
Cigarette lighter charger (12 V).
Cable for transferring data to a computer and printing field maps (USB 2.0).
Instructions.
CD-ROM with software for connecting to a computer.
