Main Characteristics
The nominal carrying capacity is 1,600 kg.
Operating mass — 5,360 kg.
The capacity of buckets is 0.8 - 0.9 m.
Overall dimensions LxWxH (mm) — 5389*1980*2795
Engine
Rated useful power — 47kW @2400rpm
The model is Yituo 4105G Stage 1
The diameter of the cylinder is 100 mm
Piston stroke — 120 mm
The working volume of the engine is 4.33 L
Max. torque — 258 Nm
Operating characteristics
Traction force on the wheel is 49 kN
Break-off force — 48 kN
Overturning load — 32 kN
Hydraulic system / Pilot control
Current
pump — 45.83 ml/rev
The pressure in the system is 16 MPa
Hydraulic cycle time:
Ascent — 3.71 s.
Unloading — 1.3 s.
(//tractor-service.com)
Lowering (empty, loading) — 2.54 s.
Total - 7.55 p.
Steering system
Angle of rotation (Left / Right) — 36°
Min. turning radius of the rear
wheel — 4,335 mm
Min. turning radius along the edge of the bucket — 4,746 mm.
Bridge
The brand is FeiCheng
Front - Fixed with calipers
Rear - Movable, on a shaky frame
Maximum rolling angles - oscillation ± 12°
Braking system
Working brakes: - Dry, with pneumohydraulic calipers
Parking brakes — Drum, pneumomechanical
Transmission
The brand is Shantui ZL15K3
Type — Intermediate shaft, switching under load
Gear speeds
Forward 1 — 6-8 km/h
Forward 2 — 20-24 km/h
Back 1 — 6-8 km/h
Back 2 — 20-24 km/h
