Tree shaker for trees, Poltava region.

A tree shaker from the Ukrainian manufacturer, cleans the fruit carefully without damaging the tree, saves you up to 90% of your time.

It is used for shaking apple, walnut, pear, cherry, plum and other fruit trees.

Product description
Advantages:

It is easily mounted to the front or rear PTO shaft on anytractor (category I or higher). It is also possible to connect to a motor-reducer and a generator, installed stationary or attached to atrailer.
Reliable arrangement of the structure (load up to 28,000 kg).
A durable tubular frame, using the latest design solutions in the field of connecting rods and drives, provide the most stable structural performance on the market offered.
The cycle of shaking a tall tree lasts about 2-3 minutes and reduces working time by at least 90% and labor consumption to a minimum.
The device is easy to use.
The effort to attach the binding tape is reduced to a minimum.
It is also suitable for shaking trees on other crops.
The use of an extendable (telescopic) metal bar when sketching a binding tape reduces the working time by 50% and excludes the use of a ladder. Labor safety increases many times over.

Technical characteristics:(//tractor-service.com)

Field of application: for shaking apple trees, pears, plums, cherries, walnuts and other fruit trees.

Powertractor: about 15 hp.
Cable length: standard 10 m; second length on request.
Cable diameter: 8 mm; the diameter of the second depends on the type of tree.
Working height: trees up to 6500 mm (Telescopic bar extends 1500 mm ― 4500 mm)
Weight: 54 kg
Telescopic rod

Principle of operation:

The strapping tape, attached to the cable on one side, is placed on the branch with the help of the hook of the telescopic rod.
With the help of the hook of the telescopic rod, the hook of the cable is attached to the loops of the binding tape.
The tree is shaken with the help of the device.
With the help of the hook of the telescopic rod, the hook of the cable is detached from the strapping tape.
With the help of a telescopic rod, the cable and the strapping tape are lowered to the ground.
