PZM-120B2 has advantages:
1) a unique reliable design, in which the wishes of farmers and grain traders were embodied;
2) an innovative hopper that allows you to change its volume and width from 2.1 to 2.9 cubic meters and 2.10 to 3 meters, respectively, in 2 minutes (this ensures comfortable transportation of grain without the need to remove the hopper and the possibility of its operation in warehouses with limited space);
3) the presence of a remote control;
4) availability of powerful lighting;
5) 4 wheels and a differential, which increased maneuverability and facilitated control of the PZM-120B2 hopper grain loader;
6) the possibility of additional equipment with scraper feeders, an auger instead of a trimmer, "Pelican", trimmer pipes of different lengths and frequency converters;
7) the trimmer is connected to the support, perfectly balanced and has a patented design that prevents
sticking of dust and imbalance of the trimmer, and also ensures automatic centering of the tape;
8) has supports with variable height, which reliably fix the bunker on the surface of the warehouse or current;
9) the trimmer pipe can be easily adjusted in height in the range of 2.5 — 4.5 m with a winch and has an original design that allows increasing the range and accuracy of grain flight.
колеса зерномета бункерного ПЗМ-120Б мають великий діаметр, що дозволяє йому легко пересуватися через поріг і т.п.
9) труба тримера може легко регулюватися по висоті в діапазоні 2,5 — 4,5м лебідкою і має оригінальну конструкцію, яка дозволяє підвищувати дальність і кучність польоту зерна.
(//tractor-service.com)
thanks to the innovative pipe of the trimmer, it is possible to load grain directly under the rear side of the trailer or grain truck. The pipe can have a length from 0.7 to 4.9 m depending on the need;
10) the electric motor of the trimmer is protected from direct ingress of dust;
11) easier and more convenient maintenance;
12) special catchers are installed under the trimmer bearing housings, which prevent damage to the housings and bearings when replacing the trimmer tape;
13) modern easily accessible bearing assemblies, electrical equipment and protection systems unified according to EU standards;
14) grain injury does not exceed 0.1%;
15) low consumption of electricity - 0.1 kV/h per 1 ton of grain.
The innovative design of the PZM-120B2 hopper allows its owner to:
- accept grain from all types of grain trucks, trailers, big-bags, buckets of front loaders, grain pipelines, silos, etc. and then load it into transport or make grain banks up to 9 m high.
- it is easy to transport PZM-120B2 even in a small trailer by jeep, minibus, etc. without the need to remove the hopper (when transporting, the hopper enlargers are removed and placed inside the main hopper);
- it is easy to maneuver between columns, supports and other obstacles in a warehouse with grain.
