Wood-burning stove Ekozhar Pro 500 horizontal, Cherkassy region.

If it is necessary to heat voluminous hangars, large production shops, warehouses, a boiler is used Ekozhar About 500. The steel chamber of the furnace is 10 mm thick with a length of 800 mm and a diameter of 520 mm. Such a furnace, in addition to a long service life, ensures the operation of the furnace on one tab for up to nine hours. To prevent unburned gases from escaping into the room, a visor is installed on the door, after the air intake pipe.

Due to the high quality of the oven and its design features, this model is also used for dryingvegetables and fruits on an industrial scale.

The air is heated in a chamber between the furnace and the furnace body, which is blown by a fan. To avoid failure of the fan, it is prohibited to attach it directly to the inlet pipe of the furnace. For this, a metal corrugated pipe should be used, and the fan should be placed below the furnace at a distance of less than 1 m.

The location of the entrance and exits can be any at the request of the customer, depending on the place of installation.

The thickness of the furnace is 8 mm.
Heating volume 500m3(//tractor-service.com)
Heating area 200m2
The size of the furnace is 800x520mm.
The diameter of the flue pipe is 160 mm.
External dimensions L1100 x W730 x H1000mm
Burning time on one full charge is up to 9 hours.
Weight 110 kg
Warranty 12 months
Efficiency 91%
The connection to the chimney is rear.
