Transporter TSN-160 B, Chernihiv region.

Transporter TSN-160 B chain scraper manure collector is intended for cleaning manure of any consistency with any type of litter from channels located along the stalls of animals when they are tethered, with simultaneous loading of it into vehicles.

TRANSPORTERS TSN-2B; TSN-3B; TSN-160A (B)

TRANSPORTERS TSN-2B; TSN-3B; TSN-160A (B) are used for mechanized removal of manure from livestock premises with simultaneous loading of manure into a vehicle.
TRANSPORTERS TSN-2B; TSN-3B; TSN-160A (B) can be used in all areas to remove manure.
When choosing a conveyor, be guided by the consistency and type of bedding.
TRANSPORTERS TSN-2B; TSN-3B; TSN-160A (B) can serve 100-120 heads of animals.
When BUYING A TRANSPORTER, compare the characteristics to select a more efficient transporter that will serve you for more than one hour!
Components of fully complete transporters
Item No. Name Quantity per set, pcs.
1 Chain with scraper 160 m. p. 1
2 Rotary device 2
3 Tension device 1
4 Rack with rollers 1
5 Tension box with rollers 1
6 Leading sprocket (large gearbox) 1(//tractor-service.com)
7 Gear reducer - large 1
8 Electric motor 4x1000 kW 1
9 Anchor bolt 17
10 Inclined camera (trough) 6m 1
11 Chain in the trough 13.2m 1
12 Rotary device (under 308 bearing) 1
13 Leading sprocket (small gearbox) 1
14 Gear reducer - small 1
15 Electric motor 2.2x1500 kW 1
16 Trough racks 1
17 Control panel 1
18 Channel gutter for all types of TSN -
