Compact disc harrow AGD 2.5N Field disc transformer, Dnepropetrovsk region.

Compactdisk harrow АГД 2.5Н Field disk transformer.Disk harrow AGD-2 5H trailed. Harrows » AGROREMMASH harrows » AGROREMMASH disc harrow AGD - 2.5H. The unit is intended for cultivating soils of different mechanical composition with crushing and embedding plant residues in the soil under the following conditions:
- soil hardness is no more than 3.5 MPa, 145
- влажность почвы не более 27%,
- the height of harvest and plant residues is up to 30 cm. The unit is designed to work with tractors of the 14 kN (1.4 ts) class. The unit can be used in all soil and climatic zones.
Trailer type
Construction width, m 2.5 minus 0.1
Productivity ha / time, 1.8...2.2
Depth of soil cultivation, cm 8...18
Operating speed, km/h 8.0...12.0
Transport speed, km/h 20
Weight of the product (without accessories), kg 1160 minus 50 Dimensions, mm, no more
length 4800 minus 150
width 2800 minus 150
height 1000 minus 150(//tractor-service.com)
Ground clearance, mm, not less than 300
Service personnel, people (tractor driver) 1
Guaranteed resource, 1240 hectares.
Transfer to transport and working position hydraulic.
Options for using AGD-2, 5H:
- as a trailing unit, it is attached to the tractor with the help of a trailing device;
- as an intermediate option, half-mounted;
- as a mounted tool, move the towing device to a vertical position, disconnect the wheel travel, hang the unit on the tractor's three-point system;
We ask you to be vigilant when choosing agricultural machinery and not to give the opportunity to unscrupulous manufacturers to impose a fake on you and thereby undermine the authority of the factory's original production!
Warranty from the manufacturer. Delivery across Ukraine. Our price is lower than the market price. Direct delivery without markup and intermediaries.
Except for seed drills SUPN is (SPCH, UPS, VESTA, KPS, KRN, OP, ZM, LDH, BGR)
Call and order - we will deliver today or tomorrow.
Call on tel. (099) 0533238, (098) 3062660
Additional information on site agroprodazha.com.ua
