Форвардер АМКОДОР 2682-01 8х8, Киев

Test sample of forwarder AMKODOR 2682-01 8x8 for work on swampy and hard-to-reach areas. It is intended for collection, loading and transportation on the territory of the forest cuttings, along haulage and logging roads of assortments and other round timber materials, as well as for carrying out loading and unloading operations, sorting and warehousing operations in the assortment technology of wood harvesting.
The eight-wheel base chassis significantly increases the machine's cross-country ability due to lower specific pressure on the soil. Thanks to a hydromechanical gearbox with a hydrotransformer, the machine is able to move over considerable distances under its own power, developing a speed of up to 28 km/h, which allows it to independently deliver the cargo to thewarehouse woodworking enterprise on its last flight. Forwarder AMKODOR 2682-01 is equipped with a front blade. Poluramy are connected to each other with the help of a horizontal-vertical hinge. When the working equipment is activated, the horizontal-vertical hinge is automatically blocked to ensure the stability of the machine. Illumination of the working area in the dark is carried out with the help of 12 headlights with halogen lamps installed on the roof of the cabin. To facilitate starting the diesel engine at low ambient temperatures, the machine is equipped with an autonomous engine pre-heater by EBERSPEHER (Germany). The comfortable operating temperature of the operator is provided by the air conditioner-heater installed in the cabin. To improve cross-country ability on swampy terrain and snow cover, the machine can additionally be equipped with tracks.
TECHNICAL DATA A-2682-01:
Carrying capacity, kg 15000
Cross-sectional area of the cargo compartment, m² 4.0
Cargo compartment length, m 4.9
Manipulator
Brand Kesla Foresteri 700-1 Kesla Foresteri 700Т
Manipulator boom reach, m 8.2 / 10.325
Lifting moment (gross), kNm 96 / 95
Load capacity at maximum reach, kg 640 / 410
Angle of rotation in the horizontal plane, ° 380
Cover diameter, mm 75...600
Coverage area, m2 0.28
Scraper
Width along the cutting edge, mm 2400
Height of blade lift, mm 1200
Engine
Brand D-260.9S2
Operating power, hp 180
Transmission
Type Hydromechanical
The number of ranges is 2
Forward/backward speed, km/h
I transmission
II transfer
III transfer(//tractor-service.com)
IV transmission

0...6.3/0...6.5
0...11.5/0...21.9
0...21.3/-
0...28/-
Traction force on I gear, kN 165
Tires
Standard size 700/50-26.5
The layering rate is 16
Dimensions and weight characteristics
Length in transport position, mm 10800
Width, mm 2 900
Height, mm 3 800
Track, mm 2 160
Base, mm 5,750
Minimum turning radius, m 10.5
Ground clearance, mm 580
Operating mass, kg 18000
Refueling tanks
Fuel tank, l 230
Hydraulic tank, l 140
ADDITIONAL SET
Manipulator with double telescope (range more than 10 m.) V
Autonomous cabin heater V
Caterpillars V
Руководство по хорошения на електронном носоем V
