Model: YTO - ELG 1754
Engine: Diesel, 6-cylinder with water cooling and preheating
Working volume, l: 6.4
Power, kW (hp): 128 (175)
Air filter: Dry
Fuel filtration system: Filter-separator for poor quality fuel + 2 fine filters
Clutch: LUK (Germany), single disc, double action, diameter 15”
KP: type/ manufacturer Mechanical / YTO (FIAT AGRI license)
Transmission: number of forward/reverse gears 18 forward / 6 reverse (with synchronizers)
Hydraulic system: Open type / separate
Hydraulic system: type
pump/drive Gear pump / with engine drive
Hydraulic system: hydraulic pump performance, l/min90
Hydraulic system: number of hydraulic outlets 3 pairs (in item 1 with flow regulation)
GDP: revolutions, rpm540 (6 slots)/1000 (20 slots)
Attachment: category/number of hydraulic cylinders Category II-III / 1 central + 2 additional hydraulic cylinders
Functions of the hinge: Power adjustment, positional adjustment, floating position.
Differential lock: Hydraulic
(//tractor-service.com)
Turning on the front axle: Mechanical
Steering: Hydraulic, independent
Size of front/rear
tires: 380/85R28 / 460/85R38
Track adjustment: front/rear, mm: 1770-2208 / 1730~2342
Working brakes: Disc, in an oil bath, with a hydraulic drive
Parking brake: Mechanical
Fuel tank capacity, l: 275
Basic dimensions: (LxWxH), mm5340x2770x3110
Wheel base, mm: 2790
Clearance, mm: 490
Operating weight, kg: 6580
Weight with counterweights, kg: 7420
Including counterweight weight, kg: 12x45 front, 4x75 rear wheels
Package of additional cabin equipment (included in the price): Air conditioner, cabin filters, heater, radio with MP3 player, 12V socket, sun blind, comfortable CRAMMER seat (with seat belt), thick continuous noise-insulating mat, plastic interior trim, tool and accessory box; single-circuit pneumatic trailer brake system with a compressor; drawbar and towing device for trailer, lever for external control of the hinge.
The Seller's warranty obligations for the Goods are valid for 1 (one) year or 1000 engine hours.
