Reversible 3-body hinged plow (solid blade) (PO-3-35+), "Polygon" Plant, Odesa region.

Note: Check the price with the seller.

Plowrevolving 3-body, it is a reliable and light plow, the strength of which is ensured by the use of a single-drawn square tube, the margin of strength of which is sufficient for plowing hard soils, high-strength steel body posts that undergo heat treatment, reinforced and strengthened rotation mechanism.

The construction of the plow is equipped with shear bolts with a diameter of 20 mm. which ensures safe operation in the event that the housings hit an obstacle. Body parts are made of high-strength steel grades that undergo a full cycle of heat treatment, which ensures an extension of their useful life.
The versatility of the design allows you to convert the plow from a 3-body to a 4-body plow and to install a support wheel, both behind the bodies and at the level of the second one. If necessary, the plow can be made with strip casings.

CHARACTERISTICS
Gripping width: 1.05 m.
Cover width: 35 cm.
Type of case: semi-screw with corner opening / strip with corner opening.
Plowing depth: 18-30 cm.
Clearance under the frame: 76 cm.
Distance between bodies: 85.5 cm.
Plow weight: 950 kg.
Tractor movement: along the furrow.(//tractor-service.com)
Suitable fortractors capacity: 80-120 hp.

ADDITIONAL OPTIONS
1. Equipment with housings with a STRIPE or PLASTIC dump; 170
2.Збільшення кількості корпусів за рахунок встановлення додаткової приставки.

ADVANTAGES
The maximally increased clearance under the frame and removal of the body from under the frame makes it possible to use the plow in fields clogged with harvest residues;
Increasing the shelf life of body parts due to the use of high-strength steel grades;
Savings during the conversion of the technical park;

The plows of the "Polygon" plant are designed for plowing various soils forgrains and technical crops to a depth of up to 30 cm, not clogged with stones, slates and other obstacles, with a specific soil resistance of up to 0.09 MPa (0.9 kgf/cm2).
