Trailed hydraulic sprayer OP-2000 / 18-21, Vinnytsia region.

Trailed hydraulic sprayer OP-2000 / 18-21- is used for processing agricultural crops with special liquid solutions. It can work with liquids of different chemicalcomposition. Effectively protects plants from pests. Treats agricultural plants from pathogenic microorganisms. It is used in the fight against weeds, to feed plants with liquid fertilizers. It is characterized by high versatility. It has a wide spray design. Equipped with a powerful (160 l / min.) pump. It has good running parameters. capacity tank for the working mixture, quality of hydraulic communications system, adjustable processing parameters. Parameters that ensure efficiency, uniformity, homogeneity of the performed processing. The boom sprayer consists of a metal frame on which a wheel axle with 2 pneumaticwheels and a coupling mechanism are attached. A hopper is mounted on a metal frame - a closed container whose task is to transport liquid substances (water, insecticides, pesticides, herbicides, fertilizers)

Type of sprayer: trailed
Barrel capacity: 2000 liters
Barrel wall thickness: 12 mm.
Plastic barrels: production in Italy
Bar grip width: 21 meters
Number of bar sections: 5 pcs.
Rod parameters: 40 x 40 x 4.5 mm. -> 25 x 40 x 2 mm.
Bar stabilization system: pendulum mechanism + shock absorbers
Type of rod construction: Parallelogram
Type of boom expansion: hydraulics / hydraulics
Boom lifting range: 1-2.2 m
Pump model: Annovi Reverberi AR160BP
Pump type: membrane-pore pump
Pump performance: 160 l / min.
Nozzle: single-position (nozzle 03)
Nozzle model: arag (Italy)(//tractor-service.com)
The nozzle connection type is a stainless steel pipe, diameter 20 mm.
Number of nozzles: 42 pcs.
Distance between nozzles: 500 mm.
Nozzle atomizer type: flat jet
Wheel size: 9.5-R32
Track width: 1.5-2.1 m.
Ground clearance: 500 mm.
Frame parameters: channel 50 x 120 x 7 mm.
Frame amplifier: 100 x 60 mm.
Seal between barrel and frame: rubber tape, thickness 3 mm.
Pump protection: protective coupling
Washing capacity 170 liters
Working speed: 8-12 km / h
Transport speed: up to 20 km / h.
Required tractor power from 60 hp.
Weight: 1600 kg.

Delivery across Ukraine.
