Trailed sprayer OP-2000 op-2500 Op-3000 liters is distinguished by a particularly strong and easy-to-use design. Trailed sprayers are available. Delivery across Ukraine. The latest design developments are embodied in the line of universal trailed sprayers.
Trailed hydraulic sprayer OP-2000-21 OPG-2000 rod 18 meters - trailed hydraulic sprayer designed for processing field crops with pesticides and liquid fertilizers. The bar is hydraulic with a grip width of -18 m, the lifting height is from 0.5 to 1.5 m. The bar is made of high-quality steel, which provides long-term use. The pendulum mechanism allows you to adjust the rod in the horizontal plane relative to the field surface.
Pump "Annovi Reverberi", manufactured in Italy, allows you to ensure uninterrupted operation of the working fluid pouring system.
The sprayers of the German company "Lechler" allow you to process plants qualitatively and effectively apply liquid
fertilizers.
Technical characteristics:
Type Trailed
Productivity for 1 hour of operating time ha / h 9-12
The working speed of movement in the main operations km / h 6-10
Working width of capture m-21
Pump (made in Italy) l / min -160
Aggregation 1.4
Tank capacity L 2000 ± 05
Use of working fluid l / ha 60-600
Working pressure in the pressure main
(//tractor-service.com)
bar 1 - 5
Transport speed, no more than km/h. - 20
Ground clearance (with horizontal placement of the sleeper), 170
Проте мм 500
Track width mm 1500 ± 50
Machine weight (structural) kg-1800
The power to drive the working bodies at a GDP turnover of 540 rpm
kW -6
Polyethylene tank with a volume of 2000 liters.
It is aggregated with tractors of class 1,4.
Additional equipment PRICE - LIST
-GPS-navigator system (Italy)
- Automated control system Computer BRAVO-180 (Italy)
-Bar lighting system (LED lamp)
-Annovi Reverberi mixer (Italy)
