Press granulator OGM-1.5
new cast body, new mechanics!

Complete set: mixer, dispenser, matrix, rollers, control board.

The granulator is a key element of the production line, which is necessary for converting biological waste into granules. The granulator is designed to produce small granules (with a diameter of no more than 14 mm), the basis of its design is a horizontally rotating ring matrix, and inside it there are two rotating rollers, their axes are fixed.

The productivity of the granulator varies depending on the granulated raw material and the selected matrix.

This model provides processing:

Woodworking production waste (shavings, sawdust, shavings, shavings);
Waste of agricultural crops (husksunflower, buckwheat, millet);
Chicken litter (allowable humidity 10%);
Stalks of reeds, hay and straw, alfalfa.
Also, this granulator can be used for the production of variouscompound feeds from cereal crops, for example, wheat and corn.

Technical parameters of the press granulator OGM-1.5

Productivity, kg/hour 700-2200
(depending on the type of raw material)

Press engine power, kW 75
Mixer engine power, kW 2.2
Dimensions (length x width x height), mm 2250x1100x2100
Type of raw material granulation all types of plant waste
Productivity during clean work kg/h
— on seed husks, if:
the diameter of the granules is 6 mm.

the diameter of the pellets is 8 mm.

the diameter of the granules is 10 mm.

700 ... 800

800 … 1000

1000 … 1200

— on wood waste, if:
the diameter of the granules is 6 mm.

the diameter of the granules is 8 mm.

the diameter of the granules is 10 mm.

700 … 800(//tractor-service.com)

800 … 1000

1000 … 1200

— on peat, if:
the diameter of the granules is 6 mm.

the diameter of the granules is 8 mm.

the diameter of the granules is 10 mm.

700 ... 800

800 … 1000

1000 … 1200

— on straw, if:
the diameter of the granules is 6 mm.

the diameter of the granules is 8 mm.

the diameter of the granules is 10 mm.

700 ... 800

900 … 1100

1100 … 1300

— according tocombined fodder, if:
diameter of pellets 3.2 mm

the diameter of the granules is 6 mm.

the diameter of the granules is 8-10 mm.

1200 ... 1500

1500 ... 2200

up to 3 tons

Connection three-phase network 380V, 50Hz
Mass, kg 1950
Cast iron body, new. 2-stage press
Warranty, month 12
We carry out delivery, installation, supervision, commissioning, warranty and post-warranty service, provision of consumables and spare parts.
