NEW Trailed harrow BDFP-2.4 (2.8-3.5-3.8-4.2) for MTZ, T-150, Dnipropetrovsk region.

NEW STAND NEW MODELTrailed disc harrow BDFP-4,2 BDFP-2,4 BDFP-2,8 BDFP-3,1 BDFP-3,5 BDFP-3,8 BDFP-4,2 (maintainless bearing unit, reinforced rolling rollers) (5210 double-row bearings)
GOS COMPENSATION 25-40% VAT, Full package of documents. Delivery across Ukraine

We present a line of BDFP disc harrows, which are currently among the best harrows on the agricultural market. BDFP harrows are equipped with maximally reinforced housings of bearings on discs, which have a high degree of reliability. The disks are installed on the hub of the bearing housing and have an optimal angle of attack that ensures the grinding of plant residues, as well as high-quality crushing, crushing and turnover of the cut layer. The optimal geometry of the angle of attack of the disks contributes to the most economical operation of the tractor. The harrow is equipped with a finishing roller and has convenient work adjustments. Adapted for work both on overdried and overmoistened land. Warranty.

Working width, m 4.2
Productivity, ha/h 3.8
Processing depth, cm 8-20
Working speed, km/h 9-12
Disc diameter, mm 650
Mass, kg 2400
Tractor power, hp 200

Characteristics
Main

Type Disc harrow
Group Heavy
Gripping width 4.2 m
The maximum processing depth is 20 cm.
The number of rows is 2
The number of disks/teeth is 24 pcs.
The power of the tractor is 200 l. p.

The harrow contains two rows of disks, each of which is located on an individual rack, which is attached to the bar with two L-shaped brackets (diameter 20 mm). This design excludes clogging of the interdisk space. The harrow can be used in all soil and climatic zones where the soil moisture does not exceed 27 percent and the soil hardness does not exceed 3.5 MPa, and it is also not recommended to use this harrow in areas with significant stony inclusions. Due to the use of individual racks in the design, the front harrow can be used at high working speeds - up to 14 km/h.

Unlike similar harrows of other manufacturers, the design of this harrow uses camomile discs (cut-out spherical) with a diameter of 650 mm, a thickness of 6 mm, made of 65G steel. During manufacture, the discs are thermally treated, which ensures a hardness of 38-46 HRC.

Disks are installed on hubs that rotate around the axis on roller bearing units at an angle of attack of 21 degrees and a vertical inclination of 21 degrees (the design is patented by the private enterprise "Agrotechkomplekt").

The metal anther, which is installed on the axis during assembly, covers the hub, forming a protective structure, which is supplemented by a sleeve with an oil seal inside and an anther outside. The unit is very well sealed from the outside environment due to this design.

The fixing and adjusting nut of the hub bearing is closed by a flange with a cap, which performs two functions:

hub sealing
fastening of the working body (BDF disk) on the hub.
The scraper is attached with two bolts with square headrests to a bracket with two grooves, which, in turn, is welded to the rack, and when the harrow is working, it cleans the working organ (disc BDF camomile) from sticking to the soil, winding plants, clogging the harvest residues, and also directs the flow of soil in the direction of the harrow and turns it.

The rear rollers of the harrow provide two functions:

- crushed soil
- compacts and aligns the surface
In addition to the functions mentioned above, with the help of a roller for hinged harrows, the depth of soil cultivation is set, which varies, as indicated above, from 8 to 18 cm.

The necessary depth of loosening and stable movement of the harrow-tractor unit is provided by a lanyard (screw mechanism with right and left thread), which provides adjustment of the vertical position of the roller.

The harrow is aggregated with tractors equipped with a hydraulic system with a capacity of from 40 (for a mounted harrow BDF-1.8) to 320 (for a trailed harrow BDFP-7.0) horsepower, depending on the width of the implement.

With the help of lanyards, the travel height (processing depth) of a plate roller with a diameter of 400 mm is adjusted.
(//tractor-service.com)
The construction of the rink attachment allows you to shift (pre-sway) the rink to the left or right (if necessary)

Trailed disk harrow - BDFP
The harrow is intended for continuous and pre-sowing soil processing of various mechanical composition for technical, grain and fodder crops and with grinding and embedding of plant residues in the soil (refreshing of sodden meadows) in various agrotechnical schemes. The adjustable processing depth is approximately 8 to 18 cm.

Trailed disc harrow BDFP-4,2BDFP-4,2
Trailed disc harrow BDFP-4,2 2
Trailed disc harrow BDFP-4,2 3
Technical characteristics.
Name BDFP-2,4 BDFP-2,8 BDFP-3,1 BDFP-3,5 BDFP-3,8 BDFP-4,2
Type Trailed
Working speed 8-12 km/h
The depth of soil treatment is 8-18 cm.
Height in transport position 1400 mm.
Height in working position 1100 mm.
Length 4940 mm.
Width 2.4 m. 2.8 m. 3.1 m. 3.5 m. 3.8 m. 4.2 m.
Productivity 1.9 Ha/h. 2.2 Ha/h. 2.5 ha/h. 2.8 Ha/h. 3.1 Ha/h. 3.4 Ha/h.
The power of the tractor is 80 hp. 100 HP 130 L.S. 160 HP 180 HP 200 HP
Transport speed, no more than 20 km/h
Number of working bodies 14 racks 16 racks 18 racks 20 racks 22 racks 24 racks
Number of rinks 1 rink 2 rink
Ground clearance, not less than 300 mm,
Transfer to the transport and working position by the hydraulic wheeled transport mechanism of the disc harrow, connected to the hydraulic system of the tractor.
Weight 1400 kg. 1630 kg. 1850 kg. 2000 kg. 2250 kg. 2400 kg.
The BDFP Trailed Harrow is produced with a working width of 2.4 to 4.2 meters. Complete with plate cylindrical rollers with a diameter of 400 mm.

Trailed disc harrow BDFP-2.4BDFP-2.4
Trailed disc harrow BDFP-2.4 2
The harrow contains two rows of disks, each of which is located on an individual rack, which is attached to the bar with two L-shaped brackets (diameter 20 mm). This design excludes clogging of the interdisk space. The harrow can be used in all soil and climatic zones where the soil moisture does not exceed 27 percent and the soil hardness does not exceed 3.5 MPa, and it is also not recommended to use this harrow in areas with significant stony inclusions. Due to the use of individual racks in the design, the front harrow can be used at high working speeds - up to 14 km/h.

BDFS harrow rack BDF-BDFP rack
Disk working body, which is a cut-out spherical disk (chamois) installed on the hub, with a diameter of 650 mm. and 6 mm thick, with internal sharpening along the entire contour. Thanks to the special geometry of the trunnion rack, it is installed at an optimal angle of attack to the line of traction and an angle to the vertical, which ensures high-quality crushing, crushing and turnover of the cut layer.

Unlike similar harrows of other manufacturers, the design of this harrow uses camomile disks (cut-out spherical) with a diameter of 650 mm and a thickness of 6 mm, made of 65G steel. During manufacturing, the discs are thermally treated, which ensures a hardness of 36-42 HRC.

Disks are installed on hubs that rotate around an axis on roller bearing (Podshipnik 5210 two-row) nodes at an angle of attack and a vertical inclination of 21 degrees.

The metal anther, which is installed on the axis during assembly, covers the hub, forming a protective structure, which is supplemented by a sleeve with an oil seal inside and an anther outside. The unit is very well sealed from the outside environment due to this design.

The fixing and adjusting nut of the hub bearing is closed by a flange with a cap, which performs two functions:

hub sealing
fastening of the working body (BDF disk) to the hub.
The scraper is attached with two bolts with square headrests to a bracket with two grooves, which, in turn, is welded to the rack, and when the harrow is working, it cleans the working organ (disc BDF camomile) from sticking soil, winding plants, clogging harvest residues, and also directs the flow of soil in the direction of the harrow and turns it.

The rear rollers of the harrow provide two functions:

crushed soil
compacts and aligns the surface
In addition to the functions mentioned above, with the help of a roller for harrows, the depth of soil cultivation is set, which varies, as indicated above, from 8 to 18 cm.
